PERAMBALUR CNC WOOD CARVING ROUTER MACHINE

3.80 Lac - 4.60 Lac / piece

1 piece (MOQ)

Business Type Manufacturer, Exporter
Brand Name Woodstar
Color Green
Condition New
Click to view more

Preferred Buyer From

Location Worldwide

Product Details

Rated Power
3-5kw,5-7kw
Automatic Grade
Automatic,Fully Automatic,Semi Automatic
Voltage
220
Type
Cnc Wood Carving Machine
Weight
1000-2000kg
After-Sales Service Provided
1
Country of Origin
India
Product Code
PERAMBALUR CNC WOOD CARVING ROUTER
Port
chennai
Payment Terms
T/T
Delivery Time
15 days

cnc router wsr-1325  stepperâ single


working area: 1500 x 2500 x 300 mm


heavy weld tube structure


hqd air cooled spindle 24000 rpm


invt taiwan vfd


richauto a11 cnc control system


yako stepper motor and drive with brake system


rapid speed 25,000 mm / min


working speed 15,000 mm / min


taiwan 20 mm high load linear rail and bearing


taiwan tbi 25mm z ball screw


german lapp cables


1.25 m helical harden rack and pinion.


timing belt gearbox


1.5 mm standard t-slot aluminium with hard pvc


support program: g codes and m codes


software: artcam and v carve aspire


lubrication: manual


voltage 220v, single phase 50hz


standard tools and accessories include allen key toolbox, ball nose tools 6 nos, spindle spanner set, 2 collet, collet nut, heavy door clamp 10 pcs, 2 sensors, servo stabilizer


12,000+ designs (800 gb)


gross weight 1200 kgs


total power 9.0 hp


overall dimension: 3200 x 2300 x 2300 mm








#woodstar cnc router 1325 servo wood carving machine in perambalur
