CNC Wood Engraving Machine
Leading Manufacturers, Exporters, Wholesaler, Distributor, Importer of Chennai Wood Cnc Router Carving Machine, Kallakurichi Cnc Wood Carving Router Machine, Namakkal Cnc Wood Carving Router Machine, Tiruppur Cnc Wood Carving Router Machine and CNC Engraving Machine from Coimbatore.
MOQ : 1 1
| Business Type | Manufacturer, Exporter |
| Brand Name | woodstar |
| Driven Type | Elecric |
| Color | Green |
| Condition | New |
| Rated Power | 9-12kw, 7-9kw, 3-5kw |
| Automatic Grade | Semi Automatic, Fully Automatic, Automatic |
| Size | 1500 X 2500 X 300 Mm |
| Voltage | 220 |
| Type | Cnc Wood Carving Machine |
| Weight | 1000-2000kg |
| Frequency | 50 |
| After-Sales Service Provided | 1 |
| Country of Origin | India |
| Table Size | 1500 X 2500mm |
| Warrenty | 2years |
| Moving speed | 60 M/min |
| Speed | 30 M/min |
| Traveling Size X Axis | 1500 |
| Traveling SizeY Axis | 2500 |
| Product Code | CHENNAI CNC WOOD ROUTER CARVING MACHINE |
| Port | chennai |
| Payment Terms | T/T |
| Delivery Time | 15 days |
Preferred Buyer From
| Location | India ( Tamil Nadu, Assam, Arunachal Pradesh, Tripura, Sikkim, Nagaland, Mizoram, Meghalaya, Manipur, Kerala only) & All other countries |
cnc router wsr-1325 servo single
working area: 1500 x 2500 x 300 mm
heavy weld tube structure
hqd air cooled spindle 24000 rpm
invt taiwan vfd
weihong nk105 g2 cnc control system
leadshine servo motor and drive with brake system
rapid speed 25,000 mm / min
working speed 15,000 mm / min
taiwan 20 mm high load linear rail and bearing
taiwan tbi 25mm z ball screw
german lapp cables
1.25 m helical harden rack and pinion.
shimpo planetary gearbox system reducer
1.5 mm standard t-slot aluminium with hard pvc
support program: g codes and m codes
software: artcam and v carve aspire
lubrication: manual
voltage 220v, single phase 50hz
standard tools and accessories include allen key toolbox, ball nose tools 6 nos, spindle spanner set, 2 collet, collet nut, heavy door clamp 10 pcs, 2 sensors, servo stabilizer
12,000+ designs (800 gb)
gross weight 1200 kgs
total power 9.0 hp
overall dimension: 3200 x 2300 x 2300 mm
MOQ : 1 piece
| Business Type | Manufacturer, Exporter |
| Brand Name | woodstar |
| Driven Type | Elecric |
| Color | Grey |
| Condition | New |
| Rated Power | 7-9kw, 5-7kw, 3-5kw |
| Automatic Grade | Semi Automatic, Fully Automatic, Automatic |
| Size | 1300 X 2500 X 250 Mm |
| Voltage | 220 |
| Type | Cnc Wood Carving Machine |
| Weight | 1000-2000kg |
| Frequency | 50 |
| After-Sales Service Provided | 1 |
| Country of Origin | India |
| Table Size | 1500 X 2500mm |
| Warrenty | 2years |
| Moving speed | 45 M/min |
| Speed | 15 M/min |
| Traveling Size X Axis | 1300 |
| Traveling SizeY Axis | 2500 |
| Product Code | KALLAKURICHI CNC WOOD CARVING ROUTER |
| Port | chennai |
| Payment Terms | T/T |
| Delivery Time | 15 days |
| Packaging Details | We are glad to introduce ourselves as Kovai Woodstar Automation and Technology Pvt Ltd, from Coimbatore, Tamil Nadu, INDIA. |
Preferred Buyer From
| Location | India ( Tamil Nadu, Assam, Arunachal Pradesh, Tripura, Sikkim, Nagaland, Mizoram, Meghalaya, Manipur, Kerala only) & All other countries |
cnc router wsr-1325 stepper single
working area: 1500 x 2500 x 300 mm
heavy weld tube structure
hqd air cooled spindle 24000 rpm
invt taiwan vfd
richauto a11 cnc control system
yako stepper motor and drive with brake system
rapid speed 25,000 mm / min
working speed 15,000 mm / min
taiwan 20 mm high load linear rail and bearing
taiwan tbi 25mm z ball screw
german lapp cables
1.25 m helical harden rack and pinion.
timing belt gearbox
1.5 mm standard t-slot aluminium with hard pvc
support program: g codes and m codes
software: artcam and v carve aspire
lubrication: manual
voltage 220v, single phase 50hz
standard tools and accessories include allen key toolbox, ball nose tools 6 nos, spindle spanner set, 2 collet, collet nut, heavy door clamp 10 pcs, 2 sensors, servo stabilizer
12,000+ designs (800 gb)
gross weight 1200 kgs
total power 9.0 hp
overall dimension: 3200 x 2300 x 2300 mm
#woodstar cnc router 1325 servo wood carving machine in kallakurichi
MOQ : 1 piece
| Business Type | Manufacturer, Exporter |
| Brand Name | woodstar |
| Driven Type | Elecric |
| Color | Green |
| Condition | New |
| Rated Power | 5-7kw, 3-5kw |
| Automatic Grade | Semi Automatic, Fully Automatic, Automatic |
| Size | 1300 X 2500 X 250 Mm |
| Voltage | 220 |
| Type | Cnc Wood Carving Machine |
| Weight | 1000-2000kg |
| Frequency | 50 |
| After-Sales Service Provided | 1 |
| Country of Origin | India |
| Table Size | 1300 X 2500mm |
| Warrenty | 2years |
| Moving speed | 45 M/min |
| Speed | 15 M/min |
| Traveling Size X Axis | 1300 |
| Traveling SizeY Axis | 2500 |
| Product Code | KARUR CNC WOOD CARVING ROUTER MACHINE |
| Port | chennai |
| Payment Terms | T/T |
| Delivery Time | 15 days |
Preferred Buyer From
| Location | India ( Tamil Nadu, Assam, Arunachal Pradesh, Tripura, Sikkim, Nagaland, Mizoram, Meghalaya, Manipur, Kerala only) & All other countries |
cnc router wsr-1325 stepper single
working area: 1500 x 2500 x 300 mm
heavy weld tube structure
hqd air cooled spindle 24000 rpm
invt taiwan vfd
richauto a11 cnc control system
yako stepper motor and drive with brake system
rapid speed 25,000 mm / min
working speed 15,000 mm / min
taiwan 20 mm high load linear rail and bearing
taiwan tbi 25mm z ball screw
german lapp cables
1.25 m helical harden rack and pinion.
timing belt gearbox
1.5 mm standard t-slot aluminium with hard pvc
support program: g codes and m codes
software: artcam and v carve aspire
lubrication: manual
voltage 220v, single phase 50hz
standard tools and accessories include allen key toolbox, ball nose tools 6 nos, spindle spanner set, 2 collet, collet nut, heavy door clamp 10 pcs, 2 sensors, servo stabilizer
12,000+ designs (800 gb)
gross weight 1200 kgs
total power 9.0 hp
overall dimension: 3200 x 2300 x 2300 mm
#woodstar cnc router 1325 servo wood carving machine in karur
MOQ : 1 1
| Business Type | Manufacturer, Exporter |
| Brand Name | woodstar |
| Driven Type | Elecric |
| Color | Red |
| Condition | New |
| Rated Power | 5-7kw |
| Automatic Grade | Semi Automatic, Fully Automatic, Automatic |
| Size | 1500 X 2500 X 250 Mm |
| Voltage | 220 |
| Type | Cnc Wood Carving Machine |
| Weight | 1000-2000kg |
| Frequency | 50 |
| After-Sales Service Provided | 1 |
| Country of Origin | India |
| Table Size | 1500 X 2500mm |
| Warrenty | 2years |
| Moving speed | 45 M/min |
| Speed | 15 M/min |
| Traveling Size X Axis | 1500 |
| Traveling SizeY Axis | 2500 |
| Product Code | TIRUPPUR CNC WOOD CARVING ROUTER MACHINE |
| Port | chennai |
| Payment Terms | T/T |
| Delivery Time | 15 days |
Preferred Buyer From
| Location | India ( Tamil Nadu, Assam, Arunachal Pradesh, Tripura, Sikkim, Nagaland, Mizoram, Meghalaya, Manipur, Kerala only) & All other countries |
cnc router wsr-1525 stepper double head
working area: 1500 x 2500 x 300 mm
heavy weld tube structure
hqd air cooled spindle 24000 rpm
invt taiwan vfd
richauto a11 cnc control system
yako stepper motor and drive with brake system
rapid speed 25,000 mm / min
working speed 15,000 mm / min
taiwan 20 mm high load linear rail and bearing
taiwan tbi 25mm z ball screw
german lapp cables
1.25 m helical harden rack and pinion.
timing belt gearbox
1.5 mm standard t-slot aluminium with hard pvc
support program: g codes and m codes
software: artcam and v carve aspire
lubrication: manual
voltage 220v, single phase 50hz
standard tools and accessories include allen key toolbox, ball nose tools 6 nos, spindle spanner set, 2 collet, collet nut, heavy door clamp 10 pcs, 2 sensors, servo stabilizer
12,000+ designs (800 gb)
gross weight 1200 kgs
total power 9.0 hp
overall dimension: 3200 x 2300 x 2300 mm
MOQ : 1 Set
| Business Type | Manufacturer, Exporter |
| Brand Name | WOODSTAR |
| Driven Type | Elecric |
| Rated Power | 3-5kw |
| Voltage | 110V, 220V |
| Type | Wood Engraving Machine |
| Country of Origin | India |
| Product Code | WOODSTAR CNC ROUTER WOOD CARVING MACHIN |
| Port | CHENNAI |
| Payment Terms | T/T |
| Delivery Time | 15 DAYS |
| Packaging Details | 3100 x 2100 x 2100 mm wooden box |
Preferred Buyer From
| Location | India ( Tamil Nadu, Assam, Arunachal Pradesh, Tripura, Sikkim, Nagaland, Mizoram, Meghalaya, Manipur, Kerala only) & All other countries |
CNC ROUTER WSR-1525 – STEPPER– SINGLE
ØWorking area: 1500×2500×300 mm
ØHeavy weld tube structure
HQD Air Cooled Spindle 24000 RPM
ØINVT TAIWAN VFD
ØWeihong NK105G2 / A11 CNC control system
ØYAKO STEPPER Motor and drive with brake system
ØRapid speed 25,000 mm / min
ØWorking speed 15,000 mm/ min
ØTAIWAN 20 mm high load linear rail and bearing
ØTAIWAN TBI 25mm z ball screw
ØGERMAN LAPP cables
Ø 1.25 M helical harden rack and pinion.
ØTiming belt gearbox
Ø1.5 mm standard T-slot aluminium with hard PVC
ØSupport program: G codes and M codes
ØSoftware: Artcam and v carve aspire
ØLubrication: Manual
ØVoltage 220V, Single phase 50hz
ØStandard tools and accessories include Allen key toolbox, ball nose tools 6 no’s, spindle spanner set, 2 collet, collet nut, heavy door clamp 10 pcs, 2 sensors, Servo Stabilizer
Ø12,000 + designs (800 GB)
ØGross weight 1200 kgs
ØTotal power 9.0 Hp
ØOverall dimension: 3200 x 2300 x 2300 mm
