CNC Sign Board Cutting Machine
Leading Manufacturers, Exporters, Wholesaler, Distributor, Importer of CNC ROUTER WSR-1530 SERVO ATC, Hybrid Servo 1325d Cnc Router Carving Machine, Kancheepuram Cnc Wood Carving Router Machine, Kanyakumari Cnc Wood Carving Router Machine and Thanjavur Cnc Wood Carving Machine from Coimbatore.
MOQ : 2 Piece
| Business Type | Manufacturer, Exporter |
| Driven Type | Electric |
| Color | Light Green |
| Condition | New |
| Power | 3-6kw |
| Automation Grade | Automatic, Fully Automatic, Manual, Semi Automatic |
| Application | Aluminium Cutting, Metal Material Cutting, Plastic Cutting, Wood Cutting |
| Certification | ISO 9001:2015 |
| Voltage | Voltage 380V,Three Phase 50hz |
| Type | Mini Cnc Router |
| Weight | 700-800kg |
| Warranty | 2years |
| Country of Origin | India |
| Working Area | 1500×3000×300 Mm |
| tube structure | Heavy weld tube structure |
| kw | 9.0 kw ATC Air Cooled Spindle 24000 RPM |
| Horizontal spindle | 6.0Kw with 2 holders |
| VFD | Fuling VFD |
| LNC control | Taiwan LNC control system with handwheel |
| Leadshine | Leadshine 1500W AC- Servo Motor and drive with brake |
| Rapid speed | 45,000 mm/min |
| Working speed | 25,000 mm/min |
| Linear Rail | Taiwan 25 Mm High Load Linear Rail and Bearing |
| Taiwan Tbi | Taiwan Tbi 32mm Z Ball Screw |
| Cables | GERMAN LAPP cables |
| Helical Harden | 1.25 M helical harden rack and pinion |
| Gearbox | JAPAN Shimpo Pl Gearbox |
| Vacuum table | Vacuum table with 11kw air vacuum pump |
| Air Pump | 5.5kw air pump with two bags Dust collector |
| Support program | Support program: G codes and M codes |
| Software | Artcam and v carve aspire |
| Lubrication | Auto Oil lubricating system |
| Accessories | Standard tools and accessories include |
| Product Code | WSR1325SERVO HT |
| Port | CHENNAI |
| Payment Terms | T/T |
| Delivery Time | 45 DAYS |
| Packaging Details | 3300 X 2300 X 2200 MM |
Preferred Buyer From
| Location | India ( Tamil Nadu, Assam, Arunachal Pradesh, Tripura, Sikkim, Nagaland, Mizoram, Meghalaya, Manipur, Kerala only) & All other countries |
Allen key toolbox, ball nose tools 6 no’s, spindle spanner set, 2 collet, collet nut, heavy door clamp 10 pcs, 2 sensors,
- Transportation
- 12,000 + designs (800 GB)
- Gross weight 1800 kgs, Total power 9.0 Hp
- Overall dimension: 3200 x 2300 x 2300 mm
- PRICE : 21,18,000 + GST18%
MOQ : 1 Piece
| Business Type | Manufacturer, Exporter |
| Brand Name | Woodstar |
| Driven Type | Elecric |
| Color | Grey |
| Condition | New |
| Rated Power | 7-9kw |
| Automatic Grade | Semi Automatic, Fully Automatic, Automatic |
| Size | 2500x1300mm |
| Voltage | 220V |
| Type | Cnc Wood Carving Machine |
| Weight | 1000-2000kg |
| Frequency | 50Hz |
| After-Sales Service Provided | Yes |
| Country of Origin | India |
| Table Size | 2500 X 1300 Mm |
| Warrenty | 2years, 1year |
| Moving speed | 45 Mm/min |
| Speed | 15 Mm/min |
| Traveling Size X Axis | 1300mm |
| Traveling SizeY Axis | 2500mm |
| Working area | 1300 × 2500 × 200 mm |
| Phase | Single Phase |
| Product Code | WOODSTAR WSR1325DSERVO |
| Port | chennai |
| Payment Terms | T/T |
| Delivery Time | 21 days |
| Packaging Details | 3200x 2300x 2100mm |
Preferred Buyer From
| Location | India ( Tamil Nadu, Assam, Arunachal Pradesh, Tripura, Sikkim, Nagaland, Mizoram, Meghalaya, Manipur, Kerala only) & All other countries |
Working area: 1500 X 2500 X 300 mm
Heavy weld tube structure
HQD Air Cooled Spindle 24000 RPM
INVT TAIWAN VFD
RICHAUTO A11 CNC control system
YAKO SERVO Motor and drive with brake system
Rapid speed 25,000 MM / MIN
Working speed 15,000 MM / MIN
TAIWAN 20 mm high load linear rail and bearing
TAIWAN TBI 25mm z ball screw
GERMAN LAPP cables
1.25 M helical harden rack and pinion.
Timing belt gearbox
1.5 mm standard T-slot aluminium with hard PVC
Support program: G codes and M codes
Software: Artcam and v carve aspire
Lubrication: Manual
Voltage 220V, Single phase 50hz
Standard tools and accessories include Allen key toolbox, ball nose tools 6 nos, spindle spanner set, 2 collet, collet nut, heavy door clamp 10 pcs, 2 sensors, Servo Stabilizer
12,000+ designs (800 GB)
Gross weight 1200 kgs
Total power 9.0 Hp
Overall dimension: 3200 x 2300 x 2300 mm
MOQ : 1 piece
| Business Type | Manufacturer, Exporter |
| Brand Name | Woodstar |
| Driven Type | Elecric |
| Color | BLUE |
| Condition | New |
| Rated Power | 7-9kw, 5-7kw |
| Automatic Grade | Semi Automatic, Fully Automatic, Automatic |
| Voltage | 220 |
| Type | Cnc Wood Carving Machine |
| Weight | 1000-2000kg |
| After-Sales Service Provided | 1 |
| Country of Origin | India |
| Warrenty | 2years |
| Product Code | KANCHEEPURAM CNC WOOD CARVING ROUTER |
| Port | chennai |
| Payment Terms | T/T |
| Delivery Time | 15 days |
| Packaging Details | We are glad to introduce ourselves as Kovai Woodstar Automation and Technology Pvt Ltd, from Coimbatore, Tamil Nadu, INDIA. |
Preferred Buyer From
| Location | India ( Tamil Nadu, Assam, Arunachal Pradesh, Tripura, Sikkim, Nagaland, Mizoram, Meghalaya, Manipur, Kerala only) & All other countries |
cnc router wsr-1325 high speed servo single
working area: 1500 x 2500 x 300 mm
heavy weld tube structure
hqd air cooled spindle 24000 rpm
invt taiwan vfd
weihong nk105 g2 cnc control system
leadshine 750w ac servo motor and drive with brake system
rapid speed 25,000 mm / min
working speed 15,000 mm / min
taiwan 20 mm high load linear rail and bearing
taiwan tbi 25mm z ball screw
german lapp cables
1.25 m helical harden rack and pinion.
shimpo planetary gearbox system reducer
1.5 mm standard t-slot aluminium with hard pvc
support program: g codes and m codes
software: artcam and v carve aspire
lubrication: manual
voltage 220v, single phase 50hz
standard tools and accessories include allen key toolbox, ball nose tools 6 nos, spindle spanner set, 2 collet, collet nut, heavy door clamp 10 pcs, 2 sensors, servo stabilizer
12,000+ designs (800 gb)
gross weight 1200 kgs
total power 9.0 hp
overall dimension: 3200 x 2300 x 2300 mm
#woodstar cnc router 1325 servo wood carving machine in kancheepuram
MOQ : 1 P
| Business Type | Manufacturer, Exporter |
| Brand Name | woodstar |
| Driven Type | Elecric |
| Color | Green |
| Condition | New |
| Rated Power | 5-7kw, 3-5kw |
| Automatic Grade | Semi Automatic, Fully Automatic, Automatic |
| Size | 1300 X 2500 X 250 Mm |
| Voltage | 220 |
| Type | Cnc Wood Carving Machine |
| Weight | 1000-2000kg |
| Frequency | 50 |
| After-Sales Service Provided | 1 |
| Country of Origin | India |
| Table Size | 1300 X 2500mm |
| Warrenty | 2years |
| Moving speed | 45 M/min |
| Speed | 15 M/min |
| Traveling Size X Axis | 1300 |
| Traveling SizeY Axis | 2500 |
| Product Code | KANYAKUMARI CNC WOOD CARVING ROUTER |
| Port | chennai |
| Payment Terms | T/T |
| Delivery Time | 15 days |
Preferred Buyer From
| Location | India ( Tamil Nadu, Assam, Arunachal Pradesh, Tripura, Sikkim, Nagaland, Mizoram, Meghalaya, Manipur, Kerala only) & All other countries |
cnc router wsr-1325 stepper single
working area: 1500 x 2500 x 300 mm
heavy weld tube structure
hqd air cooled spindle 24000 rpm
invt taiwan vfd
richauto a11 cnc control system
yako stepper motor and drive with brake system
rapid speed 25,000 mm / min
working speed 15,000 mm / min
taiwan 20 mm high load linear rail and bearing
taiwan tbi 25mm z ball screw
german lapp cables
1.25 m helical harden rack and pinion.
timing belt gearbox
1.5 mm standard t-slot aluminium with hard pvc
support program: g codes and m codes
software: artcam and v carve aspire
lubrication: manual
voltage 220v, single phase 50hz
standard tools and accessories include allen key toolbox, ball nose tools 6 nos, spindle spanner set, 2 collet, collet nut, heavy door clamp 10 pcs, 2 sensors, servo stabilizer
12,000+ designs (800 gb)
gross weight 1200 kgs
total power 9.0 hp
overall dimension: 3200 x 2300 x 2300 mm
#woodstar cnc router 1325 servo wood carving machine in kanyakumari
MOQ : 1 1
| Business Type | Manufacturer, Exporter |
| Brand Name | KOVAI WOODSTAR |
| Driven Type | Elecric |
| Color | Grey |
| Condition | New |
| Rated Power | 9-12kw, 7-9kw |
| Automatic Grade | Semi Automatic, Fully Automatic, Automatic |
| Size | 1300 X 2500 X 250 Mm |
| Voltage | 220 |
| Type | Cnc Wood Carving Machine |
| Weight | 1000-2000kg |
| Frequency | 50 |
| After-Sales Service Provided | 1 |
| Country of Origin | India |
| Table Size | 1300 X 2500mm |
| Warrenty | 2years |
| Moving speed | 45 M/min |
| Speed | 15 M/min |
| Traveling Size X Axis | 1300 |
| Traveling SizeY Axis | 2500 |
| Product Code | Thanjavur wood cnc carving machine |
| Port | chennai |
| Payment Terms | T/T |
| Delivery Time | 15 days |
Preferred Buyer From
| Location | India ( Tamil Nadu, Assam, Arunachal Pradesh, Tripura, Sikkim, Nagaland, Mizoram, Meghalaya, Manipur, Kerala only) & All other countries |
thanjavur woodstar cnc router encraving carving machine
cnc router wsr-1525 – stepper– single
øworking area: 1500×2500×300 mm
øheavy weld tube structure
hqd air cooled spindle 24000 rpm
øinvt taiwan vfd
øweihong nk105g2 / a11 cnc control system
øyako stepper motor and drive with brake system
ørapid speed 25,000 mm / min
øworking speed 15,000 mm/ min
øtaiwan 20 mm high load linear rail and bearing
øtaiwan tbi 25mm z ball screw
øgerman lapp cables
ø 1.25 m helical harden rack and pinion.
øtiming belt gearbox
ø1.5 mm standard t-slot aluminium with hard pvc
øsupport program: g codes and m codes
øsoftware: artcam and v carve aspire
ølubrication: manual
øvoltage 220v, single phase 50hz
østandard tools and accessories include allen key toolbox, ball nose tools 6 no’s, spindle spanner set, 2 collet, collet nut, heavy door clamp 10 pcs, 2 sensors, servo stabilizer
ø12,000 + designs (800 gb)
øgross weight 1200 kgs
øtotal power 9.0 hp
øoverall dimension: 3200 x 2300 x 2300 mm
rotary atttachment: 1500x200 mm
#woodstar.in, # woodstar cnc router 1325, # woodstar cnc 1325 carving machine, # woodstar cnc wood carving , # woodstar cnc wood cutting machine
