Twitter| Business Type | Manufacturer, Exporter |
| Brand Name | WOODSTAR |
| Driven Type | Elecric |
| Rated Power | 3-5kw |
| Click to view more | |
Preferred Buyer From
| Location | Worldwide |
Product Details
wooden box
CNC ROUTER WSR-1525 – STEPPER– SINGLE
ØWorking area: 1500×2500×300 mm
ØHeavy weld tube structure
HQD Air Cooled Spindle 24000 RPM
ØINVT TAIWAN VFD
ØWeihong NK105G2 / A11 CNC control system
ØYAKO STEPPER Motor and drive with brake system
ØRapid speed 25,000 mm / min
ØWorking speed 15,000 mm/ min
ØTAIWAN 20 mm high load linear rail and bearing
ØTAIWAN TBI 25mm z ball screw
ØGERMAN LAPP cables
Ø 1.25 M helical harden rack and pinion.
ØTiming belt gearbox
Ø1.5 mm standard T-slot aluminium with hard PVC
ØSupport program: G codes and M codes
ØSoftware: Artcam and v carve aspire
ØLubrication: Manual
ØVoltage 220V, Single phase 50hz
ØStandard tools and accessories include Allen key toolbox, ball nose tools 6 no’s, spindle spanner set, 2 collet, collet nut, heavy door clamp 10 pcs, 2 sensors, Servo Stabilizer
Ø12,000 + designs (800 GB)
ØGross weight 1200 kgs
ØTotal power 9.0 Hp
ØOverall dimension: 3200 x 2300 x 2300 mm
