TRICHY CNC WOOD CARVING ROUTER MACHINE

6.50 Lac - 7.50 Lac / piece

1 piece (MOQ)

Business Type Manufacturer, Exporter
Brand Name woodstar
Driven Type Elecric
Color Black
Click to view more

Preferred Buyer From

Location India ( Tamil Nadu, Assam, Arunachal Pradesh, Tripura, Sikkim, Nagaland, Mizoram, Meghalaya, Manipur, Kerala only) & All other countries

Product Details

Condition
New
Rated Power
9-12kw, 7-9kw
Automatic Grade
Semi Automatic, Fully Automatic, Automatic
Size
1500 x 2500 x 300 mm
Voltage
220
Type
Cnc Wood Carving Machine
Weight
1000-2000kg
Frequency
50
After-Sales Service Provided
1
Country of Origin
India
Table Size
1500 x 2500mm
Warrenty
2years
Moving speed
60 m/min
Speed
30 m/min
Traveling Size X Axis
1500
Traveling SizeY Axis
2500
Port
chennai
Payment Terms
T/T
Delivery Time
15 days

CNC ROUTER WSR-1325 HIGH SPEED SERVO SINGLE


Working area: 1500 X 2500 X 300 mm


Heavy weld tube structure


HQD Air Cooled Spindle 24000 RPM


INVT TAIWAN VFD


WEIHONG NK105 G2 CNC control system


LEADSHINE 750W AC SERVO Motor and drive with brake system


Rapid speed 25,000 MM / MIN


Working speed 15,000 MM / MIN


TAIWAN 20 mm high load linear rail and bearing


TAIWAN TBI 25mm z ball screw


GERMAN LAPP cables


1.25 M helical harden rack and pinion.


SHIMPO PLANETARY  GEARBOX REDUCER


1.5 mm standard T-slot aluminium with hard PVC


Support program: G codes and M codes


Software: Artcam and v carve aspire


Lubrication: Manual


Voltage 220V, Single phase 50hz


Standard tools and accessories include Allen key toolbox, ball nose tools 6 nos, spindle spanner set, 2 collet, collet nut, heavy door clamp 10 pcs, 2 sensors, Servo Stabilizer


12,000+ designs (800 GB)


Gross weight 1200 kgs


Total power 9.0 Hp


Overall dimension: 3200 x 2300 x 2300 mm
